How to use Logstash conditionals

Logstash conditionals let one pipeline choose different filter and output behavior for each event. They are useful when production errors, missing fields, parse-failure tags, and noisy debug records need different treatment before the event leaves Logstash.

Conditionals can run in filter and output blocks. They support if, else if, and else branches, nested field references such as [log][level], equality checks, regex matches, list membership with in or not in, and boolean operators such as and and or.

A temporary [@metadata][route] value keeps the routing decision out of the final event while still letting the output block act on it. The presence check if [log][level] returns false for a missing field, a false value, or null, so branch order matters when missing data needs its own route.

1. Create a temporary pipeline directory.

   $ mkdir -p /tmp/lc/p

2. Create the sample event file that exercises each branch.

   /tmp/lc/events.ndjson

   {"log":{"level":"ERROR"},"env":"prod","message":"db failed"}
   {"log":{"level":"INFO"},"env":"prod","message":"worker"}
   {"log":{"level":"DEBUG"},"env":"prod","message":"healthcheck"}
   {"env":"prod","message":"no level"}
   {"tags":["_jsonparsefailure"],"message":"bad json"}

   The records cover a production error branch, a default branch, a dropped debug branch, a missing-field branch, and an existing parse-failure tag.
   Tool: JSON Validator

3. Create the conditional pipeline file.

   /tmp/lc/p/conditional.conf

   input {
     file {
       id => "conditional_source"
       path => ["/tmp/lc/events.ndjson"]
       mode => "read"
       exit_after_read => true
       start_position => "beginning"
       sincedb_path => "/tmp/lc/sincedb"
       file_completed_action => "log"
       file_completed_log_path => "/tmp/lc/completed.log"
       codec => json
     }
   }

   filter {
     if [log][level] {
       mutate {
         id => "normalize_level"
         lowercase => ["[log][level]"]
       }
     }

     if "_jsonparsefailure" in [tags] {
       mutate {
         id => "route_invalid_json"
         add_tag => ["invalid_json"]
         replace => { "[@metadata][route]" => "invalid-json" }
       }
     } else if ![log][level] {
       mutate {
         id => "route_missing_level"
         add_tag => ["missing_level"]
         replace => { "[@metadata][route]" => "missing-level" }
       }
     } else if [log][level] == "error" and [env] == "prod" {
       mutate {
         id => "route_production_error"
         add_tag => ["production_error"]
         replace => { "[@metadata][route]" => "production-error" }
       }
     } else if [log][level] in ["debug", "trace"] or [message] =~ /^healthcheck/ {
       drop {
         id => "drop_low_value_events"
       }
     } else {
       mutate {
         id => "route_default"
         replace => { "[@metadata][route]" => "default" }
       }
     }
   }

   output {
     if [@metadata][route] {
       stdout {
         id => "show_route"
         codec => line {
           format => "%{[@metadata][route]} %{message}"
         }
       }
     }
   }

   Read mode processes the static sample once and exits after end of file. The stdout output prints only events that still have a route after filtering.
   Related: How to configure a Logstash file input
   Related: How to configure a Logstash stdout output

4. Change to the Logstash installation directory.

   $ cd /usr/share/logstash

5. Test the pipeline syntax.

   $ bin/logstash \
     --path.data /tmp/lc/data-test \
     --config.test_and_exit \
     -f /tmp/lc/p
   Using bundled JDK: /usr/share/logstash/jdk
   ##### snipped #####
   Configuration OK
   [2026-06-18T14:58:14,283][INFO ][logstash.runner          ] Using config.test_and_exit mode. Config Validation Result: OK. Exiting Logstash

   The json codec may warn about ECS compatibility because this sample keeps parsed fields at the event root. Set a codec target in production when parsed JSON keys can collide with Elastic Common Schema fields.
   Related: How to test a Logstash pipeline configuration

6. Run the pipeline against the sample events.

   $ bin/logstash --path.data /tmp/lc/data-run --log.level error -f /tmp/lc/p
   missing-level no level
   default worker
   invalid-json bad json
   production-error db failed

   The debug healthcheck record has no output because the drop branch removed it. Route output order can vary when Logstash uses multiple pipeline workers, but every non-dropped branch should appear once.

7. Remove the temporary test files.

   $ rm -rf /tmp/lc
