How to simulate an Elasticsearch ingest pipeline

Simulating an Elasticsearch ingest pipeline reveals how processors transform a document before indexing, helping catch grok mismatches, date parsing issues, and unexpected field names before they turn into mapping errors.

Ingest pipelines run on ingest-capable nodes and apply a sequence of processors (such as grok, set, rename, and date) to each incoming document. The _simulate API sends one or more sample documents through a stored pipeline and returns the transformed documents as JSON without writing anything to an index.

Simulation output shows the post-processor document, not the final indexed result, so mapping and analysis are not applied. Many environments also enable TLS and authentication, so the same request may require HTTPS, credentials, and a CA certificate depending on cluster security settings.

1. Run a basic simulation against the pipeline ID with a sample document.

   $ curl -s -H "Content-Type: application/json" -X POST "http://localhost:9200/_ingest/pipeline/parse-logs/_simulate?filter_path=docs.doc._source&pretty" -d '{
     "docs": [
       { "_source": { "message": "2025-01-22T10:15:00Z INFO app started" } }
     ]
   }'
   {
     "docs" : [
       {
         "doc" : {
           "_source" : {
             "msg" : "app started",
             "message" : "2025-01-22T10:15:00Z INFO app started",
             "level" : "INFO",
             "timestamp" : "2025-01-22T10:15:00Z"
           }
         }
       }
     ]
   }

   Secured clusters typically require https:// endpoints, authentication (basic auth or API key), and `–cacert` when using a private CA.

2. Simulate multiple documents in one request to compare edge cases.

   $ curl -s -H "Content-Type: application/json" -X POST "http://localhost:9200/_ingest/pipeline/parse-logs/_simulate?filter_path=docs.doc._source&pretty" -d '{
     "docs": [
       { "_source": { "message": "2025-01-22T10:15:00Z INFO app started" } },
       { "_source": { "message": "2025-01-22T10:16:12Z WARN cache miss" } }
     ]
   }'
   {
     "docs" : [
       {
         "doc" : {
           "_source" : {
             "msg" : "app started",
             "message" : "2025-01-22T10:15:00Z INFO app started",
             "level" : "INFO",
             "timestamp" : "2025-01-22T10:15:00Z"
           }
         }
       },
       {
         "doc" : {
           "_source" : {
             "msg" : "cache miss",
             "message" : "2025-01-22T10:16:12Z WARN cache miss",
             "level" : "WARN",
             "timestamp" : "2025-01-22T10:16:12Z"
           }
         }
       }
     ]
   }

3. Run the simulation with verbose processor output to show intermediate results for each processor.

   $ curl -s -H "Content-Type: application/json" -X POST "http://localhost:9200/_ingest/pipeline/parse-logs/_simulate?verbose=true&filter_path=docs.processor_results.processor_type,docs.processor_results.status,docs.processor_results.doc._source&pretty" -d '{
     "docs": [
       { "_source": { "message": "2025-01-22T10:15:00Z INFO app started" } }
     ]
   }'
   {
     "docs" : [
       {
         "processor_results" : [
           {
             "processor_type" : "grok",
             "status" : "success",
             "doc" : {
               "_source" : {
                 "msg" : "app started",
                 "message" : "2025-01-22T10:15:00Z INFO app started",
                 "level" : "INFO",
                 "timestamp" : "2025-01-22T10:15:00Z"
               }
             }
           }
         ]
       }
     ]
   }

   Verbose output highlights the processor responsible for each change and isolates the first failing processor when a document errors.

4. Fetch the pipeline definition before adjusting processors.

   $ curl -s "http://localhost:9200/_ingest/pipeline/parse-logs?pretty"
   {
     "parse-logs" : {
       "description" : "Parse simple timestamp/level/message log lines",
       "processors" : [
         {
           "grok" : {
             "field" : "message",
             "patterns" : [
               "%{TIMESTAMP_ISO8601:timestamp} %{LOGLEVEL:level} %{GREEDYDATA:msg}"
             ]
           }
         }
       ]
     }
   }
